8-32 & 10-32 Screw Extenders / Extensions

These extenders are used to extend the length of machine screws that are too short.

The aluminum extenders come in 1/2" and 1" sizes.

The diameter of the aluminum extenders are .1965".

The overall length of the 1/2" extender is 3/4". For the 1/2" extender, the 8-32 recess is 3/8" deep.

The overall length of the 1" extender is 1-1/4". For the 1" extender, the 8-32 recess is 7/16" deep.

The steel extender extends an 10-32 screw by 1-1/4". The steel extender is threaded 3/4" deep.

The steel extender is 1-5/8" total length. 1/4" diameter.
