3rd Point Lock For Cremone Bolt

Used with a cremone bolt to provide a 3rd point of locking.

Ninety degree operation. Shown above engaged and below retracted.

Shown in Polished Nickel finish.

Shown in a 30mm (1-3/16") backset.

Case depth: 1-13/16".

Case height: 2-11/16".

Case thickness: 1/2".

Faceplate: 3/4" wide x 4-3/16" tall.

Strike: 5/8" x 3-1/8".

Latch: 9/16" projection.
