Extra Short 2" Backset for Passage or Privacy
$55.60
Do you have stiles on your door that are too narrow to accept a standard 2-3/8" backset latch? Try this 2 inch backset latch and save 3/8 of an inch! Compatible with Emtek and many other brands. Sold as an accessory for a standard backset passage or privacy set.
To use as passage latch simply leave off privacy pin.
Dimensions:
> Backset: 2 inches.
> Barrel diameter: 1".
> Boring depth required: 3-1/8"
> Hub size: 7 mm on diamond & 8 mm on square.
> Privacy pin to hub: 23/32" center to center.
> Faceplate: 1" x 2-1/4".
When installing, the faceplate should be mounted on top of the latch on the edge of the door. This will prevent the latch from rotating. The included strike plate is mounted opposite the latch on the door jamb.
Works with Emtek passage or privacy locks using exposed screws on standard rosettes. Requires a 60 degree rotation to fully retract. Standard Emtek passage and privacy sets use a 60 degree latch. Emtek locks using concealed screws or with Stretto sideplates use only 28 degrees of rotation and are not compatible with this latch. Please note: Emtek locks with the 28 degree upgrade latch will not work with this latch. If you intend to use this latch with an Emtek lock, order the lock with the standard 60 degree latch.
Available complete with knobs. Available complete with levers. See our additional narrow backset solutions.
Works with Emtek passage or privacy locks using exposed screws on standard rosettes. Requires a 60 degree rotation to fully retract. Standard Emtek passage and privacy sets use a 60 degree latch. Emtek locks using concealed screws or with Stretto sideplates use only 28 degrees of rotation and are not compatible with this latch. Please note: Emtek locks with the 28 degree upgrade latch will not work with this latch. If you intend to use this latch with an Emtek lock, order the lock with the standard 60 degree latch.
Available complete with knobs. Available complete with levers. See our additional narrow backset solutions.
Do you have stiles on your door that are too narrow to accept a standard 2-3/8" backset latch? Try this 2 inch backset latch and save 3/8 of an inch! Compatible with Emtek and many other brands. Sold as an accessory for a standard backset passage or privacy set.
To use as passage latch simply leave off privacy pin.
Dimensions:
> Backset: 2 inches.
> Barrel diameter: 1".
> Boring depth required: 3-1/8"
> Hub size: 7 mm on diamond & 8 mm on square.
> Privacy pin to hub: 23/32" center to center.
> Faceplate: 1" x 2-1/4".
When installing, the faceplate should be mounted on top of the latch on the edge of the door. This will prevent the latch from rotating. The included strike plate is mounted opposite the latch on the door jamb.
Works with Emtek passage or privacy locks using exposed screws on standard rosettes. Requires a 60 degree rotation to fully retract. Standard Emtek passage and privacy sets use a 60 degree latch. Emtek locks using concealed screws or with Stretto sideplates use only 28 degrees of rotation and are not compatible with this latch. Please note: Emtek locks with the 28 degree upgrade latch will not work with this latch. If you intend to use this latch with an Emtek lock, order the lock with the standard 60 degree latch.
Available complete with knobs. Available complete with levers. See our additional narrow backset solutions.
Works with Emtek passage or privacy locks using exposed screws on standard rosettes. Requires a 60 degree rotation to fully retract. Standard Emtek passage and privacy sets use a 60 degree latch. Emtek locks using concealed screws or with Stretto sideplates use only 28 degrees of rotation and are not compatible with this latch. Please note: Emtek locks with the 28 degree upgrade latch will not work with this latch. If you intend to use this latch with an Emtek lock, order the lock with the standard 60 degree latch.
Available complete with knobs. Available complete with levers. See our additional narrow backset solutions.
- Shipping:
- Typically ships within 24 hours.
