Suitable for 1-3/8" and thicker doors.
Used where no visible hinge is desired. Can also be used without a door jamb.
Barring any obstructions, door is free to rotate 360 degrees.
Bear in mind that the door on one side of the pin moves away when the door on the other side of the pin moves closer. There cannot be a door stop behind the heel of the door if the door is opening outward. Consider the Hager 500 if a fine line is desired between the heel of the door and the door jamb.
See below for instructions and part details.
Clever top pin is dropped into top bearing plate by turning set screw in head of door.
Requires 1.705" of headroom in head of door to accommodate pin mechanism.
Top pin assembly measures 7/8" wide x 6-1/2" long x 1.705" tall.
Top bearing plate measures 1" wide x 5-7/8" long x 3/4" tall.
Bottom bearing plate measures 1" wide x 5-7/8" long x .341" tall.
Floor plate measures 1-1/4" x 2-5/8" x .911" tall.
Includes all necessary fasteners.
